Cold milling machine milling machines XM1003 1m width

FOB Reference Price:Get Latest Price
$80,000.00 - $88,000.00 / Set | 1 Set/Sets (Min. Order)
Brand Name:
ORIEMAC
Model Number:
XM1003
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Product name:
Cold milling machine milling machines XM1003 1m width
Operating speed:
0-32m/min
Travel speed:
0-5Km/h
Max.milling and mixing width:
1000mm
Max.milling and mixing depth:
320mm
Number of tools:
117
Milling drum diameter:
980mm
Engine model:
4 front & 5 rear
Overall dimensions:
QSC8.3
Travel mode:
Tire
After-sales Service Provided:
Overseas service center available
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Nude packing/bulk
Port
shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 10 To be negotiated

Cold milling machine milling machines XM1003 1m width



     XM1003K road milling machine is a high-performance 1m-wide/1.3m-wide milling machine mainly used for the digging and renovation of asphalt concrete pavements in highways, downtown roads, airports, cargo yards, and parking lots.

This machine is applied with advanced technologies including TTC microcomputer intelligent control technology, variable power energy-saving technology, limit load control technology, full-hydraulic four-wheel drive technology, China-III/Euro-III compliant high pressure common rail electronic injection engine technology, intelligent sprinkling control technology, engine high temperature protection technology, and construction data management technology.



With high working efficiency, simple construction processes, easy control of milling depth, easy and flexible operations, good mobility, and direct recycling of milled old material, this machine can be extensively applied for the repair, renovation, and maintenance of asphalt roads.



Description

Unit

Parameter value

Milling width

mm

1000

Milling depth

mm

300

Cutter spacing

mm

15/18

Number of cutters



100/80

Diameter ofrotor (Including cutter)

mm

930

Manufacturer



Shangchai

Cooling type



Water cooling

Model



SC9DK220G3

Rated power/2,200rpm

kW

162

Emission standard



China-III

Maximum working speed

m/min

45

Ground clearance

mm

180

Fuel tank

L

450

Hydraulic oil tank

L

130

Water tank

L

860

Machine dimensions (L×W×H)

mm

4837×2546×3745

Maximum working mass

kg

16800
