SANY 250 ton crawler crane SCC2500C

FOB Reference Price:Get Latest Price
$250,000.00 - $300,000.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Max. Lifting Height:
91.5m
Feature:
Truck Crane
Condition:
New
Place of Origin:
Hunan, China
Brand Name:
Sany crawler crane
Model Number:
SCC2500C
Certification:
ISO,GOST
Application:
Sany crawler crane
Rated Lifting Moment:
1764kN.M
Max. Lifting Load:
260t
Span:
7.6m
Color:
Red
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 year
Rated Loading Capacity:
260t
Supply Ability
Supply Ability:
2000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Nude
Port
Shanghai port
Lead Time :
In 20 days

SANY 250 ton crawler crane SCC2500C

1. Safety control system:
The two operating modes of working and assembling are convenient and rel iable; the crane has the functions of real-time display of levelness, off-line stop action,emergency electr ic control, lightning protection,automatic traveling direction adjustment,CCTV monitoring, etc., electric and mechanical devices provide safety and reliability;
2. New Design of Hoisting Operating Condition:
With 19.5m boom + 7m fixed jib, the crane may be used for hoisting shield machines for metro construction and similar products; it may automatically complete the turnover work of shield machine without an auxiliary crane; and the maximum hoisting capacity of auxiliary hook is up to 80t. The load moment Indicator can dynamically reflect the load of main hook and auxiliary hook;
3. Outstanding operating performance:
Load sensing, limit load adjustment and electro-hydraulic proportion dead slow control offer the perfect inching performance of actions, and more stable operation;
4. Reliable function assurance:
Famous brand key comonents are adopted , the designed safety margin of structures and members are sufficient;the control system can operate stably under the harsh environments like weather plateau or sand wind;
5. Convenient maintenance technology:
t takes approximately no more than 10min/person to adjust ;no more than 30min/per son for dai ly maintenance;no more than 2h/person to repair.GPS remote monitoring system is optional for maintenance and management;
6. Powerful lifting capacity:
The maximum lifting capacity of boom is 206.1t×7m=1442.7t·m,the longest boom is 91.5m;the maximum lifting capacity of luffing jib is 54.9t×16m=878.4t·m, the longest boom combination is 61.5m+61m; the heavy-duty fixed jib can turnover objects that are of a weight 80T maximumly;
7. Efficient self assembly and disassembly technology:
The whole machine can be assembled and disassembled by itself, and the assembly of basic machine only takes 3h;
8. Large-chassis design:
The chassis designed with 6.46m gauge ensures excellent operation stability within 360° slewing range;
9. 100% load travel:
Powerful lifting & travelling forces and stability offer 100% load travel;
10. Broad adaptability:
Meet certification requirements of CE, North America,Australia, Russia and Taiwan; the engine emission complies with the European and U.S. Non-highway Stage 3 Standards.
